JVC R-S33 AM/FM Stereo Receiver
The technical specifications for the JVC R-S33 AM/FM Stereo Receiver (released circa 1980) are listed below: Amplifier Section Power Output: 40 watts per channel into 8Ω (stereo) Amplifier Technology: JVC Super-A class amplification Frequency Response: 20Hz to 20kHz Total Harmonic Distortion (THD): 0.007% Signal to Noise Ratio: 77dB (MM phono input), 98dB (line-level input) Input Sensitivity: 2.5mV (MM phono), 150mV (line) Speaker Load Impedance: 4Ω minimum Equalizer & Tuner Features Built-in Equalizer: Integrated 5-band S.E.A. graphic equalizer Equalizer Bands: 40Hz, 250Hz, 1kHz, 5kHz, 15kHz (±12 dB range) Tuning Range: FM and MW (AM) bands Display Indicators: Digital LED peak power level meters, FM stereo beacon, and signal strength level LEDs. Dimensions & Weight Physical Dimensions: 450 x 120 x 345 mm (17.7" x 4.7" x 13.6") Weight: 8.1 kg (approx. 18 lbs)
The technical specifications for the JVC R-S33 AM/FM Stereo Receiver (released circa 1980) are listed below:
Amplifier Section
Power Output: 40 watts per channel into 8Ω (stereo)
Amplifier Technology: JVC Super-A class amplification
Frequency Response: 20Hz to 20kHz
Total Harmonic Distortion (THD): 0.007%
Signal to Noise Ratio: 77dB (MM phono input), 98dB (line-level input)
Input Sensitivity: 2.5mV (MM phono), 150mV (line)
Speaker Load Impedance: 4Ω minimum
Equalizer & Tuner Features
Built-in Equalizer: Integrated 5-band S.E.A. graphic equalizer
Equalizer Bands: 40Hz, 250Hz, 1kHz, 5kHz, 15kHz (±12 dB range)
Tuning Range: FM and MW (AM) bands
Display Indicators: Digital LED peak power level meters, FM stereo beacon, and signal strength level LEDs.
Dimensions & Weight
Physical Dimensions: 450 x 120 x 345 mm (17.7" x 4.7" x 13.6")
Weight: 8.1 kg (approx. 18 lbs)
