Coda PW118 Sub Package
The Coda Audio PW118 Sub Package includes several features designed for high-power, standalone sound reinforcement: Integrated Amplification & System Driving Master/Slave Setup: The PW118A active unit houses a powerful 1000 W Class D amplifier specifically engineered to drive both itself and the companion passive unit. Simplified Cabling: You can power the entire sub-package from a single mains outlet by linking the active subwoofer to the passive subwoofer via a standard speaker cable. Signal Processing & Protection Built-in Optical Limiter: Includes analog processing with an optical limiter to prevent signal clipping and protect the 18-inch drivers from damage during peak performance. Active Crossover: Features an integrated 24 dB high-pass filter output, allowing you to connect and cleanly cross over mid/high satellite speakers without needing an external processor. Premium Component Design High-Excursion Driver: Equipped with a premium 18-inch woofer featuring a 4-inch voice coil, designed for ultra-low power compression and high acoustic output. Optimized Enclosure: The cabinet utilizes a bass-reflex design with optimized porting to maximize low-frequency efficiency and minimize air turbulence noise. 🏗️ Rigging & Portability Integrated Hardware: Features built-in M20 pole mount receptacles on top for securely mounting satellite speakers. Ergonomic Handling: Built with heavy-duty handles for easier transport and includes custom protective covers to prevent scuffs during transit. Technical Specifications (PW118 / PW118 Passive Unit) Driver: 18" high-excursion woofer with low power compression Power Handling (Passive): RMS: 1000 W Program: 2000 W Peak: 4000 W Sensitivity: 98 dB (1 W / 1 m) Nominal Impedance: 8 Ohm Input Connectors: 2 x Neutrik™ NL4MP Dimensions (W x H x D): 580 x 624 x 690 mm Net Weight: 39 kg (per passive unit) Package Contents 1 x Coda Audio PW118A Active 18-inch Subwoofer (features a built-in 1000 W Class D amplifier) 1 x Coda Audio PW118 (or PW118S1) Passive 18-inch Subwoofer 2 x Protective Covers
The Coda Audio PW118 Sub Package includes several features designed for high-power, standalone sound reinforcement:
Integrated Amplification & System Driving
Master/Slave Setup: The PW118A active unit houses a powerful 1000 W Class D amplifier specifically engineered to drive both itself and the companion passive unit.
Simplified Cabling: You can power the entire sub-package from a single mains outlet by linking the active subwoofer to the passive subwoofer via a standard speaker cable.
Signal Processing & Protection
Built-in Optical Limiter: Includes analog processing with an optical limiter to prevent signal clipping and protect the 18-inch drivers from damage during peak performance.
Active Crossover: Features an integrated 24 dB high-pass filter output, allowing you to connect and cleanly cross over mid/high satellite speakers without needing an external processor.
Premium Component Design
High-Excursion Driver: Equipped with a premium 18-inch woofer featuring a 4-inch voice coil, designed for ultra-low power compression and high acoustic output.
Optimized Enclosure: The cabinet utilizes a bass-reflex design with optimized porting to maximize low-frequency efficiency and minimize air turbulence noise.
🏗️ Rigging & Portability
Integrated Hardware: Features built-in M20 pole mount receptacles on top for securely mounting satellite speakers.
Ergonomic Handling: Built with heavy-duty handles for easier transport and includes custom protective covers to prevent scuffs during transit.
Technical Specifications (PW118 / PW118 Passive Unit)
Driver: 18" high-excursion woofer with low power compression
Power Handling (Passive):
RMS: 1000 W
Program: 2000 W
Peak: 4000 W
Sensitivity: 98 dB (1 W / 1 m)
Nominal Impedance: 8 Ohm
Input Connectors: 2 x Neutrik™ NL4MP
Dimensions (W x H x D): 580 x 624 x 690 mm
Net Weight: 39 kg (per passive unit)
Package Contents
1 x Coda Audio PW118A Active 18-inch Subwoofer (features a built-in 1000 W Class D amplifier)
1 x Coda Audio PW118 (or PW118S1) Passive 18-inch Subwoofer
2 x Protective Covers
